Complete Guide to Screen Video Recording with AZ Recorder (Step-by-Step)

Complete Guide to Screen Video Recording with AZ Recorder (Step-by-Step): AZ Recorder Video Recording Tutorial

Are you looking for a reliable and straightforward way to get a professional AZ Recorder Video Recording Tutorial for your Android screen?

Whether you’re a gamer trying to capture your best highlights or a teacher needing to record step-by-step instructions, video quality, app stability, and correct audio settings are crucial for successful content. Many screen recording apps fail to deliver on quality or burden your videos with watermarks.

Fortunately, AZ Recorder (also known as AZ Screen Recorder) is one of the most powerful free tools available.
In this comprehensive guide, we will walk you through the step-by-step process of setting up AZ Recorder, mastering Its Settings, capturing internal audio recordings, and performing essential error fixes.

This AZ Recorder tutorial is complete, and all your needs for producing high-quality video content will be met right here.

Body Content

Prerequisites for Video Recording with AZ Recorder
Before you begin the AZ Recorder Video Recording Tutorial, ensure your device is technically ready.

Prerequisite	Technical Details	Essential Note
Android Version	Android 5.0 (Lollipop) and higher.	Internal Audio Recording strictly requires Android 10+.
Free Space & Battery	At least 1–2 GB free space and over 20% battery charge.	Full HD videos are large; low charge may interrupt the recording.
Storage Permission	Must grant Storage/Photos access.	Necessary for saving the recorded video files.
Pre-Recording Tips	Close notifications and enable DND (Do Not Disturb).	Prevents unwanted notifications from showing up in your video.
Overlay Permission	Must enable Display over other apps permission.	Essential for showing the AZ Recorder Floating Menu.

Installation and Preparation of AZ Recorder

To start the AZ Recorder Tutorial, you must securely install the app and grant the necessary permissions.
1. Download AZ Recorder: The best way is to download the app from the

2. Grant Necessary Permissions: Upon installation, the app will request essential permissions (such as Microphone and Storage). Be sure to approve these.

3. Activate the Floating Icon: AZ Recorder operates via a small floating icon on the screen. If you don’t see it, go to your phone’s settings and enable the “Display over other apps” permission for AZ Recorder.

Step-by-Step Video Recording Tutorial (Practical Guide)

The Floating Menu handles the main recording operation. This three-step guide will help you manage your recording like a pro.

 Step 1 – Launch the App and Access the Floating Menu

After launching, the floating menu, which holds all the controls, appears on the screen:
• Red Camera (Record): Starts recording.

• Pause Symbol: Temporarily pauses the recording.

• Square Symbol (Stop): Ends recording and saves the video.

• Gear (Settings): Accesses AZ Recorder Settings for quality and features.

• Folder (Gallery): Accesses your saved videos.

Step 2 – Start Recording and Stopping

1. Start: Tap the floating icon and press the Record button. (A 3-second countdown usually begins.)

2. Record: Deliver your content or play your game.

3. Pause: To switch apps or take a break, press the Pause button.

4. Stop and Save: To finish, pull down your notification bar or tap the floating icon, and press the Stop (Square) button. The video is instantly saved.

• Video Save Path: Videos are saved by default in a folder named AZRecorder in your phone’s internal storage.



Step 3 – Pro Tips While Recording

• Enable Show Touches for Tutorials: If you are recording an app tutorial, enable Show Touches in AZ Recorder Settings to display a white dot where your finger presses the screen. This is essential for clarity.

• Use the Start Timer: Setting the Countdown Value to 5 or 10 seconds gives you enough time to prepare your screen before the recording begins.

• Hide Notifications for Professional Videos: Activate the Hide Notification settings to keep controls hidden, even in the notification bar, resulting in a cleaner video experience.

Professional Settings for High Quality

The key to excellent AZ Recorder Recording Quality and manageable file size lies in adjusting the settings below based on your goal. This is the most critical part of AZ Recorder Settings.

Recording Goal	Resolution	FPS	Bitrate (Mbps)	Special Tip
App Tutorial	1080p	30fps	8 Mbps	Show Touches should be enabled.
Gameplay	1080p	60fps	12-16 Mbps	Close background apps for optimal performance.
Social Media	720p	30fps	6 Mbps	Set the correct aspect ratio (e.g., 9:16 for stories).

Explaining the Settings Impact:
• Resolution: Determines image clarity. 1080p is recommended for professional content.
• FPS (Frames Per Second): Affects motion smoothness. 60 FPS is vital for action/gaming, while 30 FPS is sufficient for tutorials.
• Bitrate: The main factor in AZ Recorder Recording Quality and file size. A higher Bitrate AZ Recorder means better quality, but a significantly larger file. If you experience lag, try reducing the Bitrate or frame rate first.

Audio Recording (Mic and Internal Audio)

One of the key features of any good AZ Recorder Video Recording Tutorial is the audio setup.

• Difference: Internal Audio vs. Mic: The Microphone captures your voice and ambient noise. Internal Audio captures only the sound output from apps and games.

• Internal Audio Requirement: Internal Audio Recording is restricted by the operating system and is only available on Android 10 and higher. Older Android versions can only use the microphone.

• Settings Path: Go to Settings > Audio and select the Source as Internal Audio or Microphone.

• Audio Test: Always perform a short 30-second test recording and play it back to ensure the audio source and volume levels are correctly set.

Quick Editing and FaceCam Use

You don’t need heavy software; AZ Recorder provides basic video editing tools.

• In-App Editing: After finishing, you can select the video in the gallery and choose Edit. You can trim/cut the beginning and end, merge multiple clips, and add text or background music.

• Add Logo or Watermark: You can remove the default AZ watermark in the settings. The Premium (Pro) version allows you to upload your own brand logo or watermark.

• Activate FaceCam: By enabling FaceCam, you can simultaneously place your face (via the front camera) over the screen recording. This is great for reaction videos and engaging tutorials.

Exporting and Sharing

• Output Format: Videos are usually saved in the MP4 format, the most common and compatible file type.

• File Size Reduction Tip for Faster Uploads: If the file is too large, consider reducing the Bitrate or using compression software before uploading.

• Direct Sharing: AZ Recorder provides direct share buttons for quick sharing to YouTube, WhatsApp, or Google Drive upon completion of the recording.

Fixing Common Errors

This table will help you troubleshoot the most common issues you might encounter while using this AZ Recorder Tutorial.

Error	Probable Cause	Solution
Record Failed	Missing permissions or insufficient storage space.	Check Permissions (Storage/Overlay) and ensure adequate storage.
No Sound	Android below 10 or wrong audio source selected.	Select the correct Internal/Mic audio source. If Android is below 10, only Mic will work.
Lag or Drop Frames	High Bitrate or too many background apps.	Decrease FPS (e.g., to 30) and close all background applications.
App Crash	Outdated version or corrupted cache.	Update the app to the latest version and clear the cache in your phone’s settings.

Pro Tips and Tricks

• Start Timer: Setting a start timer is the best way to ensure the screen is ready when you begin talking.

• Airplane Mode for Sensitive Tutorials: Enable Airplane Mode to prevent unwanted calls and notifications from ruining your video.

• Preset Profiles: Create and save different setting profiles (e.g., “Gaming,” “Tutorial”) for quick switching.

• Proper Lighting for FaceCam: When using FaceCam, position the window so it doesn’t cover the main content and ensure you have good lighting for your face.

Frequently Asked Questions (FAQ)

Why is the internal sound not recording?
A: Internal Audio Recording requires your device to be running Android 10 or newer. Older devices lack this capability due to system restrictions.

What are the best settings for recording gameplay?
The best settings include 1080p Resolution, 60 FPS frame rate, and a Bitrate between 12 and 16 Mbps.

Where are the recorded files saved?
They are saved by default in the AZRecorder folder in your internal storage. This path can be changed in AZ Recorder Settings.

How do I add a logo or text to the video?
Use the basic video editing in AZ Recorder tools after recording to add text. Custom logos require the Premium version.

Conclusion

You are now fully equipped with a comprehensive, step-by-step guide to mastering AZ Recorder. By utilizing the professional AZ Recorder Settings—especially controlling FPS, Bitrate, and the Internal Audio feature—you can confidently create high-quality videos for any scenario, from gaming to professional instruction. AZ Recorder is a powerful tool; with a bit of practice, it will help you produce and share your content flawlessly.
